Specifications

Fuel System: EFI – Electronic Fuel Injection
ENGINE TYPE: Yamaha-built, 357 cc, low-emission single cylinder 60° incline OHV
LUBRICATION SYSTEM: Splash-style positive oil lubrication
OIL CAPACITY: 1 U.S. quart (1 liter, 1,000 cc)
AIR CLEANER: Two-stage, urethane-foam pre-cleaner, and high-capacity pleated paper cartridge
COOLING SYSTEM: Forced Cooling
STARTING SYSTEM: Starter generator with pedal start system

• Dry Weight: QuieTech EFI: 714.3 lb (324kg), Drive2 EFI: 681.2 lb (309 kg), PowerTech AC: 617.3 lb (280 kg), Drive2 AC: 595.2 lb (270 kg)
• Curb Weight: QuieTech EFI: 344 kg (758 lb), Drive2 EFI: 324 kg (714 lb), PowerTech Li: 341.3 kg (752 lb), Drive2 AC: 443 kg (977 lb) Drive2 Li: 328 kg (723 lb)
• Tire Size: 18 x 8.5 – 8 (4-ply rating)
• Seating Capacity: 2 persons
• Available Model Colors: Sunstone, Evergreen, Bluestone, Carbon, Moonstone, Pearl, Glacier
• Available Seat Color: Standard: Stone Optional: Black
• Available Suntop Color: Standard: Stone Optional: Black

• Overall Length: 93.6 in (238 cm)
• Overall Width: 47.3 in (120 cm)
• Overall Height(with suntop): 70.2 in (178 cm)
• Wheelbase: 64.4 in (164 cm)
• Front Wheel Tread: 34.8 in (88 cm)
• Rear Wheel Tread: 38.3 in (97 cm)
• Floor Board Height: 12.9 in (33 cm)
• FRAME: HybriCore™ Chassis features a robotic welded automotive ladder-style steel frame protected with a multi-step full-immersion phosphate treatment, electro-deposition epoxy-based coating, and an electrostatic applied polyester/urethane powder topcoat.
• STEERING: Self-compensating double reduction helical rack-and-pinion.
• FRONT WHEEL SUSPENSION: Tru-Trak II™ fully independent automotive-style strut suspension.
• REAR WHEEL SUSPENSION: QuieTech EFI and PowerTech AC: Fully independent automotive-style strut suspension. Drive2 EFI and Drive2 AC: Swing arm with coil springs over hydraulic shock absorbers.
• BRAKES: Self-adjusting mechanical, rear wheel drum brakes.
• BUMPERS Front and rear 5 mph energy-absorbing bumpers.
• Maximum Forward Speed: 15.0 mph (24 km/h)
• Minimum turning radius: 9.2 ft (2.8 m
