Power

Power Source: 56.7 V Max
Horsepower/kW:  14.9 hp (11.1 kW) Peak
Electrical System:  48 VDC
Key/Pedal Start:  Pedal
Speed Controller:  350 Amp AC
Drivetrain:  Direct-Drive AC Induction Motor

Dimensions

Overall Length: 142.8 in (363 cm)
Overall Width: 50.6 in (129 cm)
Overall Height: (w/o Roof) 51 in (130 cm)
Overall Height: (w/ Roof) 74.5 in (189 cm)
Wheel Base:  99.5 in (253 cm)
Front Wheel Track:  38.5 in (98 cm)
Rear Wheel Track:  38.5 in (98 cm)
Ground Clearance:  6.1 in (15.5 cm)

Performance

Dry Weight:  966 lb (438 kg) (Without Batteries
Curb Weight:  1100 lb (499 kg)
Load Capacity:  1047 lb (475 kg)
Outside Clearance:  25.5 ft (7.8 m)
Speed:  Up to 19 mph ± 0.5 mph (Up to 30.6 kph ± 0.8 kph)

Steering & Suspension

Steering: Self-Compensating Rack and Pinion
Suspension: Leaf Springs with Hydraulic Shock Absorbers
Service Brake: Rear Wheel Mechanical Self-Adjusting Drum
Parking Brake: Automatic Electro-Magnetic (ELiTE Only)
Tires: Paramount SBR Tire on 14” FTV Alloy Wheel

Body & Chassis

Frame: Welded Steel with E-Coat and DuraShield™ Powder Coat
Body & Finish: Injection Molded TPO
