Dimensions

Overall Length: 114.7 in (291 cm)
Overall Width: 47.0 in (119 cm)
Overall Height: (w/o Roof) 47.0 in (119 cm)
Overall Height: (w/ Roof)75.0 in (191 cm)
Wheel Base: 66.0 in (168 cm)
Front Wheel Track:  34.5 in (88 cm)
Rear Wheel Track:  38.5 in (98 cm)
Ground Clearance:   4.0 in (10 cm)

Power

Power Source: 56.7 V
Horsepower/kW: 4.4 hp (3.3 kW) Continuous
Electrical System: 48 VDC
Key/Pedal Start: Pedal
Speed Controller: 235-amp Solid-State AC Controller
Drivetrain: Direct-Drive AC Induction Motor
Transaxle: Limited Slip Differential
Gear Selection: Dash Mounted Forward-Neutral-Reverse
Rear Axle Ratio:  16:99:1
Batteries (Qty/Type):  ELiTE 2.2, Single 56.7V Max Lithium
Battery Charger:  Light World Charger, 56.7V, 10 ft DC Cord

Performance

Dry Weight:  892 lbs (405 kg)
Curb Weight:  939 lbs (426 kg)
Load Capacity:  800 lb (360 kg)
Outside Clearance:  19.2 ft (5.9 m)
Speed:  19 mph ± 0.5 mph (31 kph ± 0.8 kph)

Steering & Suspension

Steering:  Double-Ended Rack and Pinion
Suspension: Independent A-Arm Coil Over Shock (Front) – Mono-Leaf Spring With Hydraulic Shocks (Rear)
Service Brake:  Induction Motor
Parking Brake:  Automatic Electro-Magnetic

Body & Chassis

Frame:  Welded Steel with Durashield Powder-Coat Protection
Body & Finish:  Injection Molded TPO
